firelight — Caller ID
Published: 2001-04-04 22:13:59 +0000 UTC; Views: 697; Favourites: 1; Downloads: 199
Redirect to original
Description
This was me and a friends final project in the class "Once Chip Based Computers". This is a "fully" functional caller ID with the ability to store three numbers! Not bad since we were lazy. It is programmed with an Assembler programmer and we built this little circuit up. Extra features: An LED indicating the incoming signals. Oh yeah baby. Got ourselfs A's on this!Related content
Comments: 5
got this on random deviation
👍: 0 ⏩: 0
hey cool man, i learn assembler too, hate it, nice work, thats probably --cking hard to do ah? so ill guess i am going to mov so bx to cx cya later
-=[-RetrO-]=-
Head of OPTICO
From The Eye To The Brain
http://www.optico.f2s.com
👍: 0 ⏩: 0
The controller is the Motorola 68705(thinkthats the name) that the programming code is in. It's the on up against the LCD. The smaller chip up front is the MITEL MT8870DN chip that converts the code from the phone line to ones and zeroes. The sourcecode for this might be availible soon
👍: 0 ⏩: 0
lol. Very cool!!!
|- syph0n -|
|- This filthy planet wont know what hit it once I uncover its secrets...Ahh! These contacts are itchy! -|
👍: 0 ⏩: 0
Heheh, cool. What microcontroller is the brains of the thing?
