Sonic840 — PowerPC CPU frame redo
by-nc-sa
#cpu
Published: 2016-12-24 07:27:24 +0000 UTC; Views: 3504; Favourites: 12; Downloads: 115
Redirect to original
Description
I redid my other PPC CPU frame. White on black is much more readable. I also swapped out most of the CPU cards in favor of the naked processors. Only down side is the POWER6+ CPU I had broke when I removed the cap. What is it with IBM and alternating between thermal grease and thermal cement in the same MCM?updated photo - 2021-01-03
Related content
Comments: 4
In Cell's description I see an extra 'd' (coprocessord).
Nice tableau of Powers! I have a few of them myself. The "bluray" 601 and 603 are beautiful beasts!
I feel bad for the Power5 but I know how hard is to remove the heatsink from those modules. Actually, I just couldn't, that's why I didn't keep it in the end
👍: 0 ⏩: 0
Very slick presentation. I think the bare processor presentation looks much cleaner. My only note of 'critique' would be that it looks like a space got dropped in formatting for the description of the Espresso chip.
👍: 0 ⏩: 1
Indeed, i was stuck at home with vision problems when I worked on this project. Looks like I missed a few type-os...
👍: 0 ⏩: 1
That's ok. It looks awesome anyways, even with a few type-os.
