Description
Torquil was drawn up shortly after the delivery of Agda and her sisters. He was originally going to be a 0-4-0 tender engine intended for goods traffic but it was decided that he would be experimentaly fitted with an extended frame, trailing wheel and a rear water tank and coal bunker. This made him the first tank engine of the railway. He could under trails pull a heavy train for about 11 kilometres before having to top up on water. He was put into service as a shunting, banking and local goods engine and was considered quite the success. Most of the railways following tank engines would follow the same basic arrangement of a water tank and coal bunker placed behind the footplate.
A special thanks to www.deviantart.com/keisser for his help with the mathematics.

Dimensions
Length over Buffers: 4.600 mm
Width: 1.750 mm
Height: 3.000 mm
Rigid wheelbase: 2.340 mm
Gauge: 1.067 mm

Driving wheel Ø: 1.067 mm
Running wheel Ø: 615 mm
Cylinder Ø: 250 mm
Stroke: 400 mm

Boiler
Boiler Ø: 825 mm
Boiler lagging Ø: 890 mm
Length: 2.065 mm
Firebox: 850 x 420 mm
Evaporation surface: 23,9 m²
Steam output: 954 kg/h
Working pressure: 3,5 Bar

Speed and Power
Tractive effort: 12,9 kN
Top speed: 85 km/h
Optimum speed: 60 km/h
Effect 32 km/h: 46,8 kW
Max load (2% incline): 545 ton
2.650 kg/axle

Fuel
Coal cap: 0,275 m³ = 300 kg
Water cap: 350 l
